MS852B
Bluetooth 2D Imager Scanner
Combining mobility wireless design and durability at an affordable price, MS852B 2D barcode reader is ideal for a wide range of applications and industry sectors.
-
Wireless
-
Bluetooth
-
2D
-
IP42
-
2.1M
-
Retail
-
Logistics
-
Warehousing
-
Manufacturing
Combining mobility wireless design and 2D scanning performance in one scanner, the unitech MS852B wireless scanner delivers the simple way to do the inventory control faster and efficiency for business solutions from warehousing, manufacturing, logistics to general-purpose retail scanning.
Features
• Support most 1D / 2D barcode on mobile screens, even damaged or poorly printed barcodes
• Support Bluetooth® dual-mode technology (Bluetooth LE® V4.2 & Bluetooth® 2.1+EDR, Class 1)
• Wireless transmission range up to 100m in the line of open sight.
• Long battery life up to 40 hours per a fully charged battery
• Durable design: IP42 and 2.1m drop spec
• Auto Bluetooth pairing / Auto switch between Trigger & Presentation mode with cradle
Move without Restrictions
Featuring 2D scanning technology, the MS852B has the ability to capture most 1D / 2D barcodes on mobile screens, even damaged or poorly printed barcodes. Moreover, the MS852B supports Bluetooth® dual mode technology (Bluetooth LE® V4.2 & Bluetooth® 2.1+EDR, Class 1) to give you the freedom and bring your business the flexibility. It is compatible with any smartphone, tablet, or computer–the MS852B pairs easily to any mobile device or PC. Besides, it allows users to transmit data to the host from up to 100 meters from the base.
User-Friendly with Cradle Accessory
This MS852B wireless scanner has a cradle accessory that supports auto Bluetooth® pairing and it has the ability to switch between trigger or presentation mode automatically. When it is out of range reading in Auto Mode, the scanned data will be saved into the MS852B memory buffer automatically and transmit to the host when back to the wireless coverage. Moreover, MS852B can be set to batch mode reading, all the scanned data will be stored in a memory buffer and upload to your devices at your own convenience.
Compact but Durable
|
While sustaining a 2.1-meter drop to concrete, MS852B incorporated with IP42 rugged design for protection against dust and moisture. Moreover, the built-in long lifecycle trigger of 10 million times guarantees a continuous productivity for the best reliability. This scanner can be used in the most practical way depending on the scanning task in various solutions in retail, warehousing, manufacturing, logistics. |
|
|
|||
| IP42 Certification |
2.1m Drop Protection |
||
Specification
System
- Memory 7.5MB (590,000 barcodes)
- Key Trigger Key
Optical & Performance
- Sensor CMOS sensor with 640 x 400 pixel
- Aiming Element 610nm
- Illumination Hyper Red 660nm
- Ambient Light 10000 ft. candles (107,639 lux)
- Skew Angle ±60°
- Pitch Angle Sensor ±60°
- Roll Angle 0 - 360°
- Optical Resolution 5.0 mil (Code 39), 6.6 mil (PDF417)
- Printing Contrast Scale Minimum 20%
-
Depth of Field
(DOF PCS=80%)
-------------------------------------------------------SYMBOLOGY / X-DIM TYPICAL RANGE* Near Far
5 mil Code 39 2.0 in / 5.1 cm 6.4 in / 16.2 cm
5 mil Code 128 2.5 in / 6.3 cm 5.0 in / 12.7 cm
6.6 mil PDF417 2.5 in / 6.3 cm 6.3 in / 16.0 cm
10 mil PDF417 1.8 in / 4.5 cm* 9.0 in / 22.8 cm
13 mil 100% UPC 2.0 in / 5.0 cm* 12.5 in / 31.7 cm
20 mil Code 39 2.0 in / 5.0 cm* 19.5 in / 49.5 cm
20 mil Data Matrix 1.5 in / 3.8 cm 13.5 in / 34.3 cm
20 mil QR Code 1.5 in / 3.8 cm 11.0 in / 27.9 cm
Communication
-
Radio
Bluetooth LE® V4.2
& Bluetooth® 2.1+EDR, Class 1
Dual mode - Wireless Coverage 100m ( line of sight)
- Interface/ Profile Serial Port and HID profiles
- Host Interface supported USB, RS232
Mechanical
- Dimension 87.8 L x 71.6 W x 177.7 H (mm)
- Weight 213g without cradle
- Trigger Switch Life 10 million times
- Cradle Dimension 120.6 L x 88.7 W x 86.0 H (mm)
Symbologies
- 1D Barcodes All major symbologies and PDF417
-
2D Barcodes
2D :QR Code, Data Matrix, Aztec Code, PDF417, Macro PDF417, Micro PDF417, MaxiCode, Coda block A, Codablock F, GS1Composite, Han Xin Code
Postal: Australian Post, British Post, Canadian Pos, InfoMail, Intelligent Mail Bar Code, Japanese Post, KIX (Netherlands) Post, GS1 Composite, Korea Post, Planet Code, Postal, Postnet - Data Formatting Prefix, Suffix, Code ID, Reformatting Date
Electrical
- Indicator LED & Beeper & Vibrator
- Battery Type Rechargeable and replaceable battery pack.
- Battery Capacity 2850mAh
- Battery Charging time <6.5 hours
- Operating Time >40 hours
Environmental
- ESD Protection Functional after 8K Contact and 15K Air
- Mechanical Shock 2.1M onto concrete (scanner only)
- Operating Temperature -10°C to 50°C (14°F to 122°F)
- Storage Temperature -40°C to +70°C (-40°F to +158°F)
- Relative Humidity 95% non-condensing
- IP Rating IP42
Accessories
-
Accessories(Optional)
■ USB cable (PN# 1550-905890G)
■ RS232 cable (PN# 1550-905891G)
■ USB type C cable (PN# 1550-905892G)
■ 1-slot charging cradle (PN#5 000-900064G)
■ Battery pack (PN# 1400-900055G)
Regulatory Approvals
- Regulatory Approvals CE, FCC, BSMI, VCCI, NCC, TELEC, BQB
What comes in the box
-
The standard package contents
■ MS852B Scanner with battery
■ Cradle
■ Interface cable
